Paths : Home > Products > Shoulder Shaped Male and Female Pre-insulating Joint

Summary Parameter

gonbre-Shoulder shaped male and female pre-insulating joint (2).jpg

Section of lead:0.5 - 1.5 mm² (USA Spec 22 - 16 ) Imax = 10A
ITEMNO	NEMATAB	Dimension
	t	B	B1	H	D Φ	d Φ	L
	mm	mm	mm	mm	mm	mm	mm
PBDD 1.25-250	0.8*6.35	7.4	6.3	10	3.8	1.7	21.5

Section of lead:1.5 - 2.5 mm² (USA Spec 12 - 10 ) Imax = 15A
ITEMNO	NEMATAB	Dimension
	t	B	B1	H	D Φ	d Φ	L
	mm	mm	mm	mm	mm	mm	mm
PBDD 2-250	0.8*6.35	7.4	6.3	10	4.3	2.3	21.5

Section of lead:1.5 - 2.5 mm² (USA Spec 12 - 10 ) Imax = 15A
ITEMNO	NEMATAB	Dimension
	t	B	B1	H	D Φ	d Φ	L
	mm	mm	mm	mm	mm	mm	mm
PBDD 2-250	0.8*6.35	7.4	14	5.7	3.4	2.3	25
